MEMORIA RAM KINGSTON DIMM DDR4 VALUE RAM 3200MHZ

Descripción

MEMORIA RAM KINGSTON DIMM DDR4 VALUE RAM 3200MHZ CL22 1GX64BIT 1RX8 (KVR32N22S8L/8)

DDR4 3200MT/s Non-ECC Unbuffered DIMM CL22 1RX8 1.2V 288-pin 8Gbit

This document describes ValueRAM’s KVR32N22S8/8 is a 1G x 64-bit
(8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8,
memory module, based on eight 1G x 8-bit FBGA components. The
SPD is programmed to JEDEC standard latency DDR4-3200 timing of
22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. The
electrical and mechanical specifications are as follows:

• Power Supply: VDD = 1.2V Typical
• VDDQ = 1.2V Typical
• VPP = 2.5V Typical
• VDDSPD = 2.2V to 3.6V
• Nominal and dynamic on-die termination (ODT) for
data, strobe, and mask signals
• Low-power auto self refresh (LPASR)
• Data bus inversion (DBI) for data bus
• On-die VREFDQ generation and calibration
• Single-rank
• On-board I2 serial presence-detect (SPD) EEPROM
• 16 internal banks; 4 groups of 4 banks each
• Fixed burst chop (BC) of 4 and burst length (BL) of 8
via the mode register set (MRS)
• Selectable BC4 or BL8 on-the-fly (OTF)
• Fly-by topology
• Terminated control command and address bus
• PCB: Height 1.23” (31.25mm)
• RoHS Compliant and Halogen-Free
